Allen-Bradley PowerFlex 6000 User Manual

136 Rockwell Automation Publication 6000-UM002E-EN-P - April 2018
Appendix C Preventative Maintenance Schedule
ATTENTION: Customers can replace components for the PowerFlex 6000 drives.
However repairs must only be performed by qualified Rockwell Automation
personnel.
Table 11 - Preventative Maintenance Schedule (0...10 yrs.)
Interval Period (in years from commissioning date)
012345678910Component
Location
Component
Category
Component/Item
Isolation
Transformer
Cabinet
Air-cooling system Door Mounted Air Filters C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R
Top-mounted Cooling
Fans
IIIIRFB/RIIIIRFB/R
Integral MagneticsIsolation Transformer IIIIIIIIII
LV Control Isolation Transformer
Temperature Monitor
IIIIIIIIII
Voltage Sensing Board IIIIIIIIII
Power
Module
Cabinet
Air-cooling system Door Mounted Air Filters C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R
Top-mounted Cooling
Fans
IIIIRFB/RIIIIRFB/R
Power Module Electrolytic Capacitors
(1)
IIIIIIRIII
Misc. HECS IIIIIIIIII
LV
Control
Cabinet
Misc. AC/DC Power Supplies IIIIIIIIII
UPS UPS
(2)
IIIIIIIIII
LV Control PLC IIIIIIIIII
Control Unit IIIIIIIIII
HMI IIIIIIIIII
LV Control Relays IIIIIIIIII
LV Control Circuit Breakers IIIIIIIIII
All Connections LV Component Terminal &
Plug-in Connections
IIIIIIIIII
Medium Voltage Cable
Connections
IIIIIIIIII
Transformer Secondary
Winding Connections
IIIIIIIIII
Power Module Input and
Output Power
Connections
IIIIIIIIII
General Enhancements Firmware — — Rv — — Rv — — Rv Rv
Hardware —— Rv —— Rv —— Rv —
Operational
Conditions
Parameters / Variables I IRvI IRvI IRvI
Spare Parts Inventory Needs I I Rv I I Rv I I Rv I
(1) Based on worst case scenario – full load/speed operation at 8700 hours per year at 40 °C ambient temperature.
(2) Fully discharge and recharge the UPS batteries every 6 months, to extend battery life.
