Allen-Bradley PowerFlex 6000 User Manual

Rockwell Automation Publication 6000-UM002E-EN-P - April 2018 137
Preventative Maintenance Schedule Appendix C
ATTENTION: Customers can replace components for the PowerFlex 6000 drives.
However repairs must only be performed by qualified Rockwell Automation
personnel.
Table 12 - Preventative Maintenance Schedule (11...20 yrs.)
Interval Period (in years from commissioning date)
11 12 13 14 15 16 17 18 19 20Component
Location
Component
Category
Component/Item
Isolation
Transformer
Cabinet
Air-cooling system Door Mounted Air Filters C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R
Top-mounted Cooling
Fans
IIIIRFB/RIIIII
Integral MagneticsIsolation Transformer IIIIIIIIII
LV Control Isolation Transformer
Temperature Monitor
IIIIIIIIII
Voltage Sensing BoardIIIIIIIIII
Power
Module
Cabinet
Air-cooling system Door Mounted Air Filters C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R
Top-mounted Cooling
Fans
IIIIRFB/RIIIII
Power Module Electrolytic Capacitors
(1)
IIIRIIIIII
Misc. HECS IIIIIIIIII
LV
Control
Cabinet
Misc. AC/DC Power SuppliesIIIIIIIIII
UPS UPS
(2)
IIIIIIIIII
LV Control PLC IIIIIIIIII
Control Unit IIIIIIIIII
HMI IIIIIIIIII
LV Control Relays IIIIIIIIII
LV Control Circuit BreakersIIIIIIIIII
All Connections LV Component Terminal &
Plug-in Connections
IIIIIIIIII
Medium Voltage Cable
Connections
IIIIIIIIII
Transformer Secondary
Winding Connections
IIIIIIIIII
Power Module Input and
Output Power
Connections
IIIIIIIIII
General Enhancements Firmware — Rv — — Rv — — Rv — —
Hardware — Rv — — Rv — — Rv — —
Operational
Conditions
Parameters / Variables I Rv I I Rv I I Rv I I
Spare Parts Inventory Needs I Rv I I Rv I I Rv I I
(1) Power Modules are refurbished at factory as part of an exchange program.
(2) Fully discharge and recharge the UPS batteries every 6 months, to extend battery life.
