Rockwell Automation Publication 6000-UM002E-EN-P - April 2018 76
Parameters and Function Codes Chapter 4
P281 Low Voltage Ride Through Min Time
Interval
0 1000101010101010101010101010s On/OffYY
P282 Low Voltage Ride Through Min
Frequency Limit
5 100555555555555 OfflineYY
P283 Low Voltage Ride Through Enable
0 = Disable
1 = Enable
0 1111111111111 On/OffYY
P284 Low Voltage Ride Through Min Time
Limit
10 16383 40 40 40 40 40 40 40 40 40 40 40 40 ms Offline Y
P285 Low Voltage Ride Through Max Time
Limit
10 16383 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms Offline Y
P286 Low Voltage Ride Through Recovery
Frequency Compensation Factor
-200.00 199.99 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 Offline Y
P287 Low Voltage Ride Through Recovery
Time
10 16383 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 ms Offline Y
P288 Low Voltage Ride Through System
Delay Correction Factor
-10000.00 10000.00 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 μs Offline Y
P289 Low Voltage Ride Through Motor
Speed Estimation Filter Time
0.98 1000.00 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 ms Offline Y
P290 Voltage Loop Enable
0 = Disable
1 = Enable
0 1111111111111 Offline Y
P291 SVC Low Frequency Acceleration
Time Enable Frequency Range
Upper Limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 % On/Off Y
P292 SVC Low Frequency Acceleration
Time
1 3276.7555555555555sOn/Off Y
P293 SVC Flux Voltage Boost Coefficient 0 500 300 300 300 300 300 300 300 300 300 300 300 300 % On/Off Y
P294 SVC Flux Voltage Boost Upper
Frequency
0 100 10 10 10 10 10 10 10 10 10 10 10 10 % On/Off Y
P295 Iq Filter Time For Slip Estimation 0 1000 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P296Current Feedback Filter Time 0 1000101010101010101010101010msOn/Off Y
P297Voltage Feedback Filter Time 0 1000101010101010101010101010msOn/Off Y
P298 Filter Time A For DC Bus Average
Value
0 1000 100 100 100 100 100 100 100 100 100 100 100 100 ms On/Off Y
P299 Filter Time B For DC Bus Average
Value
0 1000555555555555msOn/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
