81 Rockwell Automation Publication 6000-UM002E-EN-P - April 2018
Chapter 4 Parameters and Function Codes
P398 DC Bus Upper Limit 0 32767 800 800 1050 1050 1000 1000 1050 1050 1050 1050 1050 1050 V On/Off Y Y
P399 Deceleration Time 1.0 3276.7 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 s On/Off Y Y Y
P401 Acceleration Time 1.0 3276.7 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 s On/Off Y Y Y
P402 Acceleration Ramp Transition Time 0.00 100.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 % On/Off Y
P403 Acceleration Time Unit
1000 = 0.01 s
10000 = 0.1 s
0.0 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 On/Off Y
P405 Deceleration Ramp Transition Time 0.00 100.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 % On/Off Y
P406 Deceleration Time Unit
1000 = 0.01 s
10000 = 0.1 s
0.0 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 On/Off Y
P408 Flying Start Compensation Defer
Restore Voltage Speed Current
Threshold
20.00 399.99 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 On/Off Y
P409 Amplification Coefficient Of Error
Term s
0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 On/Off Y
P410 Flying Start Compensation Current
Threshold for Fast Compensation
0.00 399.99 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 On/Off Y
P411 Over Speed Lower Limit Reference 0 100 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P412Over Speed Lower Limit Reference0 100000000000000 On/Off Y
P413Frequency Command Lower Limit-100100000000000000 On/Off Y
P414 Frequency Command Deadband
Upper Limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 Offline Y
P415 Frequency Command Upper Limit -100 100 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P416 Flying Start Mode
0 = Disable
1 = Set Frequency
2 = Stop Frequency Plus 5 Hz
3 = Maximum Output Frequency
0 3000000000000 On/OffYY
P417 Flying Start Motor Speed Search
Timeout
0 1000505050505050505050505050s On/OffYY
P418 Acceleration Time 1 1.0 3276.7 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 s On/Off Y Y
P419 Acceleration Frequency 1 0 75 10 10 10 10 10 10 10 10 10 10 10 10 On/Off Y Y
P420 Acceleration Time 2 1.0 3276.7 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 s On/Off Y Y
P421 Acceleration Frequency 2 0 75 20 20 20 20 20 20 20 20 20 20 20 20 On/Off Y Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
