Allen-Bradley PowerFlex AFE User Manual

Rockwell Automation Publication 20Y-TG001C-EN-P - April 2017 129
Appendix E
AFE Power One-line System Application Data
Data to Collect
Collect the following AFE system data before contacting Allen-Bradley® drives
technical support.
AFE
SCR Bus
Supply
Drive
Motor
Drive
Motor
Cable Length:__________________________Cable Type:________________________________
Cable Length:__________________________Cable Type:________________________________
Line Reactor Mfgr./Cat. No.:__________________________% Impedance:_______________
Isolation Xfmr Mfgr./Cat. No.:__________________________% Impedance:_______________
Input Contactor
AFE Cat. No.:____________________________SCR Cat. No.:_____________________________
Output Contactor
Cable Length:___________________________Cable Type:______________________________
Drive Cat. No.:________________________________________________________________
Output Reactor Mfgr./Cat. No.:_________________________________________________
Terminator Mfgr./Cat. No.:_________________________________________________
Cable Length:__________________________Cable Type:_______________________________
Utility Transformer Delta-Delta, Delta-Wye, or Other
Typ e
Input Volts
Output Volts
kVA
Z None, Solid, High Resistive
Ground
Secondary Transformer
Typ e
Input Volts
Output Volts
kVA
Z None, Solid, High Resistive
Ground
Motor Manufacturer
Volts
Amps
RPM
Hz
Power
Design No.
Encoder
Brake
Motor Heater
