130 Rockwell Automation Publication 20Y-TG001C-EN-P - April 2017

Appendix E AFE Power One-line System Application Data

Typical Transformer Winding

Types

The diagrams in this section show typical transformer winding types.

Figure 48 - Delta-Wye with Grounded Wye Neutral

Figure 49 - Delta-Delta with Grounded Leg, or Four-Wire Connected Secondary Delta

Figure 50 - Ungrounded Secondary
