Appendix A
Service Tools and Equipment
Software Tools
Connected Components Workbench™ software, DriveExecutive™ software, or
DriveExplorer™ software are tools that can be used to upload, download, and
monitor system parameters.
Service Tools
This table describes the basic tools that are needed for repair and maintenance.
Item Description Details
1 Oscilloscope Portable, digitizing, dual-channel scope with isolation
2 Current clamp 1000 A (AC, rms), signal output
3 High-voltage differential probe P5210 or equivalent
4 Soldering station Soldering/de-soldering
5 Flashlight —
6 Multi-meter Digital multimeter, capable of AC and DC voltage, continuity, resistance, capacitance measurements, and forward diode bias tests.
Fluke Model 87 III or equivalent.
7 Insulation tester 1000V DC
8 Torque wrench 1…12 N•m
9 Torque wrench 6…50 N•m
10 Box wrench 7 mm, 8 mm, 10 mm, 13 mm, 17 mm, 19 mm, 22 mm
11 Socket extension 230 mm
12 Wrench 7 mm, 8 mm, 10 mm, 13 mm, 17 mm, 19 mm, 22 mm
13 Allen wrench —
14 Wire cutter —
15 Needle-nose pliers —
16 Crimping tools For cable terminals 1, 5…240
17 Angle wrench —
18 Screwdriver 7 x 2 mm
19 Pozidriv screwdriver #1, #2, #3
20 Phillips screwdriver #1, #2, #3
21 Torx screwdriver #25
22 Hexagonal wrench #4, #5, #6
23 ESD-protected place of work Working surface, floor covering, seat, and ground connections
24 ESD-protective clothing Wrist wrap, shoes, overall clothing (coat)
25 Power supply (service) Capacity of three-phase service 400/500/690V AC, 30 A
26 20-MAINSTND maintenance stand Maintenance stand for removing power structure from AFE enclosure
27 Fiber-optic repair kit Agilent HFBR-4593 Polishing Kit, with Polishing Fixture, 600 grit abrasive paper, and 3 mm pink lapping film (3M Company, OC3-14).
For Agilent HFBR-4532 latching connectors and HFBR-RL cable. See Agilent publications 5988-9777EN and 5988-3625EN.
