POINT I/O Module and RSLogix 5000 Software Controller Tag Reference 115
To enter values from +128…+255, use these conversion formulas:
Desired Decimal Position Value - 256 = Entered Decimal Position
Value.
As an example, for a divisor of 200, 200 - 256 = -56
Desired Gate Interval Value - 256 = Entered Gate Interval Value.
As an example, for a Gate Interval of 200, 200 - 256 = -56
Desired Scalar Value - 256 = Entered Scalar Value.
As an example, for a Scalar of 128, 128 - 256 = -128
1734-VHSC24
1 Channel 15…24V DC Very High-speed Counter
1734-VHSC5
1 Channel 5V DC Very High-speed Counter
Configuration Data Data Type Default
Value
Valid Data Values
SS Output Control
SS Out 0 Force
SS Out 0 En
SS Out 0 Electronic Fuse
SS Out 0 Diagnostic Speed
SS Out 1 Force
SS Out 1 En
SS Out 1 Electronic Fuse
SS Out 1 Diagnostic Speed
SINT
BIT 0
BIT 1
BIT 2
BIT 3
BIT 4
BIT 5
BIT 6
BIT 7
0
0=Output Off
1=Output Forced On
0=Output Disabled
1=Output Enabled
0=Auto Retry
1=Latch Off
0 <
8 ms Response
1=50 ms Response
0=Output Off
1=Output Forced On
0=Output Disabled
1=Output Enabled
0=Auto Retry
1=Latch Off
0 <
8 ms Response
1=50 ms Response
