Publication 1734-UM011D-EN-P - May 2011
Quick Start 139
The Rockwell Software RSLinx Gateway - [RSWho - 1] screen appears.
TIP
The RSWho screen is actually RSLinx’s network browser
interface, which lets you view all of your active network
connections.
The left pane of this display is the Tree Control, which
shows networks and devices in a hierarchical view. When a
network or device is collapsed, as indicated by the + sign,
you can click the + sign or double-click the network or
device icon to expand the view and begin browsing. When
a network or device is expanded, as indicated by the - sign,
you can click the - sign or double-click the network or
device icon to collapse the view. The right pane of the
RSWho display is the List Control, which is a graphical
representation of all of the devices present on the network.
TIP
If there is a communication status error with a device (for
example, when a recognized device is inadvertently
unplugged), that device appears with a red X, indicating
that RSWho previously recognized it, but now it cannot.
You can choose to remove the device from the RSWho
display, or you can choose to correct the communication
error.
