x530L Series Installation Guide for Virtual Chassis Stacking
47
The LEDs display link status and activity. The possible LED states are
described in Table 15.
Table 15. Link and Activity Status LEDs for the 1Gbps and 10Gbps Ports
State Description
Solid Green The transceiver has established a 10Gbps
link to a network device.
Flashing Green The transceiver is transmitting or receiving
data in 10Gbps.
Solid Amber The transceiver has established a 1Gbps
link to a network device.
Flashing Amber The transceiver is transmitting or receiving
data in 1Gbps.
Off Possible causes of this state are:
- The port is empty.
- The transceiver has not established a link
to a network device.
- A non-supported module is installed.
- The LEDs are turned off. To turn on the
LEDs, use the eco-friendly button.
