Chapter 3 Handling
3
Paper feeding direction
70 mm (Backing paper width)
66.0 mm (Label width including fringes)
63.0 mm (Print area width)
60.0 mm (Label width)
35.0 mm
(Label Length)
38.0 mm
(Print area Length = BlackMark Interval)
1.5 mm
Black mark position
Backing paper
Label area
Printing data position
(Top: 63.0 × 38.0 mm rectangular/Bottom: 63.0 × 38.0 mm oval)
1.5 mm
2.0 mm
1.5 mm
1.5 mm
2.0 mm
1.5 mm
1.5 mm
1.5 mm
Print area specified in [User Defined Media Layout] in the printer
driver
