Chapter 6 Appendix
6
Printing Specifications
dpi : dots per 25.4 mm (dots per inch)
Paper Specifications
The following is the type and the size of paper specified for this printer.
Printable area Roll paper Minimum width 26 mm, Maximum width 104 mm
Fanfold paper Minimum width 46 mm, Maximum width 104 mm
Print speed 360 × 360 dpi
(horizontal × vertical)
Printing width 56 mm: 103 mm/s, 72 mm: 96 mm/s,
104 mm: 85 mm/s
720 × 360 dpi
(horizontal × vertical)
Printing width 56 mm: 52 mm/s, 72 mm: 48 mm/s,
104 mm: 42 mm/s
When using paper other than the specified, users must evaluate the recognition rate in
advance to avoid deterioration of the paper feed accuracy/barcode recognition rate/print
quality and frequent occurrence of paper jams.
Depending on the temperature and humidity, the synthetic labels and paper backing have
different ratios of expansion and contraction, and this causes the paper to curl. If the paper
curls, the paper may be rubbed by the print head and become contaminated, or the paper
may jam.
Do not use the paper which is extended by connecting with tape and others. The paper may
be detected incorrectly by the connected line, and rubbed by the print head and become
contaminated, or the paper may jam.
Paper type Category Form Width
Continuous paper Plain
Matte
Roll paper 30 to 108 mm
{1.18 to 4.25"}
(Paper width)
Continuous paper (Blackmark) Plain
Matte
Roll paper 30 to 108 mm
{1.18 to 4.25"}
(Paper width)
Continuous paper (Blackmark) Plain
Matte
Fanfold paper 50 to 108 mm
{1.97 to 4.25"}
(Paper width)
Full-page label
Transparent full-page label
Plain label
Matte label
Synthetic label
Glossy label
Roll paper 25.4 to 108 mm
{1 to 4.25"}
(Label width)
Die-cut label (Gap)
Transparent die-cut label
Plain label
Matte label
Synthetic label
Glossy label
Roll paper 25.4 to 108 mm
{1 to 4.25"}
(Label width)
