201
Chapter 6 Appendix
6
Continuous paper (Blackmark)
Media type Plain / Matte
Media source Roll paper
Paper width 30 to 108 mm {1.18 to 4.25"}
Black mark width 13 mm {0.51"} or more
Black mark length 4 mm {0.16"} or more
(with a width of at least 4 mm around)
Center of a black mark 8.5 mm  1 mm {0.33  0.039"}
Gaps between black marks 8 to 1117.6 mm {0.32 to 44"}
Paper thickness 0.084 to 0.124 mm {0.003 to 0.004"}
Paper core External diameter: 44.1 mm {1.74"} or more
External diameter Maximum 101.6 mm {4"}
Winding direction Printing face must be facing outside.
Do not use the paper with a hole or cutout.
Perforation position
0.5 mm or more
(When using fanfold
paper)
Black mark width
Center of black marks
Black mark length
Interval of black marks
Center of paper width
<Back side> <Printing side>
Center of paper
width
Paper feeding
direction
Black mark
receipt
