Chapter 6 Appendix
6
Wristband
Media type WB-S/M/L series (Synthetic media)
Media source Roll paper
Paper width WB-S/M/L series: 36 mm {1.42"}
Black mark width 13 mm {0.51"} or wider
Black mark length 4 mm {0.16"} or more
(with a width of at least 4 mm around)
Center of a black mark 8.5 mm 1 mm {0.33 0.039"}
Gaps between black marks WB-S: 184.1 mm {7.25"}
WB-M: 292.1 mm {11.5"}
WB-L: 292.1 mm {11.5"}
Paper thickness WB-S/M/L series: 0.225 mm {0.0088"}
Paper core External diameter 56.8 mm or more
External diameter Maximum 101.6 mm {4"}
Winding direction Printing face must be facing outside.
Hole, notch Diameter: 2.5 mm or less
Black mark width
Center of black marks
Black mark length
Interval of black marks
Center of paper width
<Back side>
<Printing side>
Center of paper width
Paper feeding
direction
Black mark paper
