Chapter 6 Appendix
6
When "Borderless Printing" is enabled
Top, bottom, left, right margins: 0 mm (Typical value)
If you enabled "Borderless Printing", printing is done with settings for no margins, but the
printing might protrude beyond the paper/label, depending on the actual print position and
the set position for the paper/label. To make sure printing does not protrude out, ensure mar-
gins of 1.5 mm {0.06"} or more in the print data.
Even if "Borderless Printing" is enabled, the maximum value for the print area width is 104
mm {4.09"}.
Paper width
Issuing pitch (Ph)
Auto-cut position
Auto-cut position
Paper feeding
direction
Print area
Interval of perforated lines (Pm)
Perforated line
Auto-cut position
Perforated line
Center of paper width
Print area width
Black mark
position
0.5 to 1.0 mm
15.0 mm or more (When
auto cut is not per-
formed: 8.0 mm or more)
