DE1-SoC User Manual
10
www.terasic.com
March 14, 2014
M
M
e
e
m
m
o
o
r
r
y
y
D
D
e
e
v
v
i
i
c
c
e
e
 64MB (32Mx16) SDRAM on FPGA
 1GB (2x256Mx16) DDR3 SDRAM on HPS
 Micro SD card socket on HPS
C
C
o
o
m
m
m
m
u
u
n
n
i
i
c
c
a
a
t
t
i
i
o
o
n
n
 Two port USB 2.0 Host (ULPI interface with USB type A connector)
 UART to USB (USB Mini-B connector)
 10/100/1000 Ethernet
 PS/2 mouse/keyboard
 IR emitter/receiver
 I2C multiplexer
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
s
s
 Two 40-pin expansion headers
 One 10-pin ADC input header
 One LTC connector (one Serial Peripheral Interface (SPI) Master ,one I2C and one
GPIO interface )
D
D
i
i
s
s
p
p
l
l
a
a
y
y
 24-bit VGA DAC
A
A
u
u
d
d
i
i
o
o
 24-bit CODEC, Line-in, Line-out, and microphone-in jacks
V
V
i
i
d
d
e
e
o
o
I
I
n
n
p
p
u
u
t
t
 TV decoder (NTSC/PAL/SECAM) and TV-in connector
A
A
D
D
C
C
 Fast throughput rate: 1 MSPS
 Channel number: 8
 Resolution: 12-bit
