Amada IS-300A - Page 110

IS-300A
10. Specifications
10-5
 Output Cables
If a customer procures the cable by oneself, prepare it in accordance with the
following right-hand specifications.
Type Model No. Length
Specifications of Standard
Cable
For
transformer
with M6
terminal
PK-1173690 2 m Rated voltage 600 V AC min.
PK-1173691 5 m Section area 14 mm
2
min.
PK-1173692 10 m No. of cores 3
For
transformer
with M8
terminal
PK-1173693 2 m Cable dia. 25 mm max.
PK-1173694 5 m
PK-1173695 10 m
Type Model No. Length
Specifications of CE Marking
Compliant Cable
For
transformer
with M6
terminal
PK-1173696 2 m Rated voltage 600 V AC min.
PK-1173697 5 m Section area 16 mm
2
min.
PK-1173698 10 m No. of cores 3
For
transformer
with M8
terminal
PK-1173699 2 m Cable dia. 25 mm max.
PK-1173700 5 m
Compliance
standard
Conductor:
VDE0812/0281
Insulation:
VDE0250/0281
PK-1173701 10 m
 SENS Cables
Type Model No. Length
For our
dedicated
transformer
(ITH-651□6W)
SK-05741-002 2
m
SK-05741-005 5 m
SK-05741-010 10 m
For our
conventional
transformer
(IT-512□)
SK-07527-002 2
m
SK-07527-005 5 m
SK-07527-010 10 m
 Others
Item Model No. Length
Circuit cable
SK-1176504 2 m
SK-1176505 5 m
SK-1176506 10 m
SK-1176507 15 m
SK-1176508 20 m
Toroidal coil
MB-400L
(Belt, 470 mm approx.)
Cable,
2.8 m
MB-800L
(Belt, 890 mm approx.)
