IS-300A
9. External Communication Function
9-7
(5) Data Code Table
Screen 01 (SCHEDULE data) Specific data in accordance with Schedule No.
(Schedule No.: 001 to 255)
Item Contents
Character
string
Range
1 Control mode of WE1 n,
0: Primary constant-current
effective value control
1: Secondary constant-current
effective value control
2: Secondary constant-power
effective value control
3: Primary constant-current peak
value control
4: Secondary constant-voltage
effective value control
5: Constant-phase control
2 Control mode of WE2 n,
3 Control mode of WE3 n,
4 Unit of time *
1
n, m: ms C: CYC
5 SQD / Squeeze delay time nnnn,
0000 to 9999 (ms mode)
0000 to 0999 (CYC mode)
6 SQZ / Squeeze time nnnn,
0000 to 9999 (ms mode)
0000 to 0999 (CYC mode)
7 UP1 / Upslope 1 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
8 WE1 / Weld 1 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
9 DOWN1 / Downslope 1 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
10 COOL1 / Cooling 1 time nnnn,
0000 to 9999 (ms mode)
0000 to 0999 (CYC mode)
11 UP2 / Upslope 2 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
12 WE2 / Weld 2 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
13 DOWN2 / Downslope 2 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
14 COOL2 / Cooling 2 time nnnn,
0000 to 9999 (ms mode)
0000 to 0999 (CYC mode)
15 UP3 / Upslope 3 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
16 WE3 / Weld 3 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
17 DOWN3 / Downslope 3 time nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
18 HOLD / Hold time nnnnn,
00000 to 20000 (ms mode)
00000 to 00999 (CYC mode)
19 OFF / Off time nnnn,
0000 to 9990 (ms mode)
0000 to 0099 (CYC mode)
20 CURRENT RANGE n, 0: 05 1: 10 2: 20 (kA)
21 UF1 / Initial heat 1 of upslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
22 HEAT1 / Heat 1
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
