IS-300A
9. External Communication Function
9-8
Item Contents
Character
string
Range
23 DL1 / End heat 1 of downslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
24 UF2 / Initial heat 2 of upslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
25 HEAT2 / Heat 2
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
26 DL2 / End heat 2 of downslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
27 UF3 / Initial heat 3 of upslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
28 HEAT3 / Heat 3
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
29 DL3 / End heat 3 of downslope
nn.n,
01.0 to 20.0 (kA, kW)
10.0 to 99.9 (%)
n.nn,
0.50 to 9.99 / 0.05 to 5.00 (kA, kW)
0.20 to 9.99 (V)
30 PULSATION of WELD1 nn, 01 to 19
31 INTERVAL 1 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
32 PULSATION of WELD2 nn, 01 to 19
33 INTERVAL 2 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
34 PULSATION of WELD3 nn, 01 to 19
35 INTERVAL 3 nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
36
WELD TRANS FREQ /
Welding transformer frequency
nnnn,
0600 to 3000 (Hz)
Note) The last 2 digits are fixed to
00.
37 GAIN n, 01 to 09
38 VALVE n, 1 to 2
39 TURN RATIO nnn.n, 001.0 to 199.9
40 WELD ON/OFF n, 0: OFF 1: ON
41 VOLT COMPENSATION nnn,
Fixed to 3 digits (000 to 100) (%)
42 PULSE LIMIT of WELD1 nn.n,
Fixed to 4 digits (10.0 to 99.9) (%)
43 PULSE LIMIT of WELD2 nn.n,
Fixed to 4 digits (10.0 to 99.9) (%)
44 PULSE LIMIT of WELD3 nn.n,
Fixed to 4 digits (10.0 to 99.9) (%)
45 MAX CURRENT nn,
01 to 20 (kA)
46 TRANS # n
1 to 5
*1 The setting of ms/CYC cannot be changed. You can change it via Screen 05
(SYSTEM data). When setting, use the same value as the read value.
