9. External Communication Function
9-9
 Screen 02 (MONITOR SET screen) Specific data in accordance with Schedule No.
(Schedule No.: 001 to 255)
Item Contents
Character
string
Range
1 TIME HI of WE1 (upper limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
2 TIME LO of WE1 (lower limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
3 CURRENT HI of WE1 (upper limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
4 CURRENT LO of WE1 (lower limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
5 VOLT HI of WE1 (upper limit) n.nn, 0.00 to 9.99 (V)
6 VOLT LO of WE1 (lower limit) n.nn, 0.00 to 9.99 (V)
7 POWER HI of WE1 (upper limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
8 POWER LO of WE1 (lower limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
9 PULSE HI of WE1 (upper limit) nnn, 010 to 100 (%)
10 TIME HI of WE2 (upper limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
11 TIME LO of WE2 (lower limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
12 CURRENT HI of WE2 (upper limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
13 CURRENT LO of WE2 (lower limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
14 VOLT HI of WE2 (upper limit) n.nn, 0.00 to 9.99 (V)
15 VOLT LO of WE2 (lower limit) n.nn, 0.00 to 9.99 (V)
16 POWER HI of WE2 (upper limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
17 POWER LO of WE2 (lower limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
18 PULSE HI of WE2 (upper limit) nnn, 010 to 100 (%)
19 TIME HI of WE3 (upper limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
20 TIME LO of WE3 (lower limit) nnn,
000 to 999 (ms mode)
000 to 050 (CYC mode)
21 CURRENT HI of WE3 (upper limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
22 CURRENT LO of WE3 (lower limit)
n.nn, 0.00 to 9.99 (kA)
nn.n, 00.0 to 99.9 (kA)
23 VOLT HI of WE3 (upper limit) n.nn, 0.00 to 9.99 (V)
24 VOLT LO of WE3 (lower limit) n.nn, 0.00 to 9.99 (V)
25 POWER HI of WE3 (upper limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
26 POWER LO of WE3 (lower limit)
nn.nn, 00.00 to 99.99 (kW)
nnn.n, 000.0 to 999.9 (kW)
27 PULSE HI of WE3 (upper limit) nnn.n 010.0 to 100.0 (%)
