IS-300A
4. How to Operate Screens
4-37
!01001:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 1)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
!01002:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 2)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
!01003:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 3)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
 The error data of the schedule having errors is transferred after the
monitor data is sent.
Ex. 2) Current caution (E08) and pulse width caution (E09) for
schedule 1, and voltage caution (E18) and power caution
(E19) for schedule 3 in Ex. 1)
!01001:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 1)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
!01002:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 2)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
!01003:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 3)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
!01001:E08,09[CR][LF] (schedule 1)
!01003:E18,19[CR][LF] (schedule 3)
 The monitor data of the schedule having no error and error data
are transferred if an error occurs when END SIG MODE is 2.
Ex. 3) No-current error (E07) for schedule 2, and current caution
(E08) for schedule 2 in Ex. 1)
!01001:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 1)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
!01003:m,120,1.20,0.50,0.60,20.0,200,2.00,1.50,3.00,40.0,300 (schedule 3)
,2.50,2.00,5.00,50.0,2,0010,5,0100,0,100000,2222,555555[CR][LF]
!01002:E07[CR][LF] (schedule 2)
!01003:E08[CR][LF]
(Note 4) The thermo detection function of the transformer changes depending
on the scan mode setting.
OFF: Detects the thermo error of the transformer with Pin 20
(THERMOSTAT) on the terminal block for external input/output
signal.
1-1 to 1-5: Detects the thermo error of the transformer with the
Welding transformer [I/O] connector. (Refer to 5.(3).)
(r) COMM CONTROL
Selects a communication function.
OFF
No communication
-->
One-way communication
<->
Both-way communication
(s) COMM MODE
Selects a communication mode.
RS-485
Communication by RS-485
RS-232C
Communication by RS-232C
