Structure and function, carrier vehicle
BAG0166.5 12.18
Brake pedal
Always use the brake pedal for emergency braking.
• The machine can be slowed down using
ο the brake pedal.
ο the driving lever.
→ The delay via the driving lever may be sufficient depending on
the driving situation.
•
When braking using the brake pedal, the slowing down is carried
out by the pneumatic brake system and the hydrostatic drive.
Braking with the brake pedal
• Until standstill:
→ Before continuing to drive, briefly put the driving lever in the
neutral position.
• To reduce the forward speed:
→ After the brakes are released, the machine accelerates to the
speed selected using the driving lever.
Light module
(1) No function
(2) Battery charger lamp
(3) Indicators of the machine
(4) High beam display
(5) No function
(6) No function
34
