Amazone Pantera 4502 - Operating Elements, Safety and Maintenance

Structure and function, carrier vehicle
76
Pantera 4502 CP1_E3A_E4 BAG0166.5
12.18
5.15.7 Operating elements, Safety and Maintenance
Fig. 40
(1) Hazard warning light switch
(2)
Switch for travelling on the road / driving on fields with
locking mechanism in road travel position
(3)
Button for manual lubrication by the lubricating device
(Option)
(4)
Switch for the mirror heating
(5)
Switch for the warning beacon (Option)
5.15.7.1 Road travelling / field travelling
Road mode: Push rocker switch downwards.
• Only two-wheel steering possible.
• No cruise control function.
• Warning when driving with ladder lowered.
• Warning: Track width set according to the type approval.
Field mode: Unlock rocker switch
and push upwards.
• Speed limited to 20 km/h.
• Warning when driving with ladder lowered.
