2.1.4 Harmonic Measurements (CSW series)
Parameter Range
Accuracy ( )
Resolution
Frequency fundamental 16.00 - 1000 Hz 2 counts 0.01 Hz to 1 Hz
Frequency harmonics 32.00 Hz - 16 kHz
2 typ. 0.5
Voltage Fundamental 0.25V 0.01V
Harmonic 2 - 50 0.25V + 0.1% + 0.1%/kHz 0.01V
Current Fundamental !% of Range 0.01A
Harmonic 2 - 50 1% of Range + 0.1%/kHz 0.01A
Harmonics frequency range in three-phase mode is 32 Hz - 16 kHz. Measurement bandwidth is limited to 16 Khz.
