User Manual California Instruments
CSW Series 89
3.14 Standard Measurements
Standard measurements are always available through the MEAS key on the front panel. These
measurements are spread across two to four screens to enhance readability. Switching between
these screens can be done by successively pressing the MEAS button on the front panel. This
will cause the screen to cycle through all available measurement screens.
3.14.1 CSW Series Measurements
For CSW Series, the following four measurement screens are available:
Mode AC DC AC+DC
MEASUREMENTS 1
VOLTAGE AC rms voltage DC Voltage AC rms voltage
CURRENT AC rms current DC Current AC rms current
FREQUENCY Frequency n/a Frequency
POWER Real power Power n/a
MEASUREMENTS 2
VA POWER Apparent power power Apparent power
PEAK CURR Highest AC current
found
Highest DC current
found
Highest AC
current found
POWER FACT Power factor n/a Power factor
CREST FACT Crest factor n/a Crest factor
MEASUREMENTS 3
VOLT THD Voltage distortion n/a Voltage distortion
CURR THD Current distortion n/a Current distortion
INST PK CURR Instantaneous peak
current
Highest DC current
found
Instantaneous
peak current
PHASE Phase angle n/a Phase angle
The CSW Series has a fourth measurement screen for harmonics and trace analysis
measurements. This subject is covered in the next chapter.
Measurements are always running in the background. When the user selects a measurement
screen for display, the AC source first updates all the measurement parameters before
displaying the requested screen. This process may take up to a second. Consequently, pressing
the MEAS key may not always bring up the selected screen immediately. There will be a
perceptible delay. This will prevent the screen from appearing with invalid or blank readouts.
The measurement method for voltage and current will depend on the power source operating
mode. The following table shows the return value type (rms or average) and method of coupling
when the measurement command is initiated with a different extension at various operating
modes (AC, DC or AC + DC).
Measurement
Extension
and Coupling
Operating Mode
AC DC AC + DC
AC rms rms rms
DC rms rms average
Coupling AC DC DC
