Ametek CSW5550 - Mechanical; Environmental

User Manual California Instruments
24 CSW Series
2.2 Mechanical
Parameter Specification
Dimensions: 19” (483 mm) wide x 8.75” (222 mm) high x 23.5” (597 mm) deep
chassis size which is available in a rack mount or stand-alone
configuration.
Unit Weight: 126.5 lb. (57.2 kg)
Material: Steel chassis and front panel, Aluminum top cover and rear panel.
Finish: Light textured painted external surfaces.
Front and rear panels semi-gloss polyurethane color no. 26440
(medium gray)
Top, bottom and sides semi-gloss polyurethane color no. 26622 (light
gray).
Cooling: Fan cooled with air intake on the sides and exhaust to the rear.
Internal
Construction:
Modular sub assemblies.
Rear Panel
Connections:
(see section 3 for description of connections)
Input terminal block with cover
Output terminal block with cover
Remote voltage sense terminal block with cover
System interface (not for table top use, use only in rack enclosed
systems)
Clock and Lock (not for table top use, use only in rack enclosed
systems)
RS232, GPIB, USB, LAN (option)
2.3 Environmental
Parameter Specification
Operating Temp:
0 to +45 C (32F to 113F)
Storage Temp:
-40 to +70C.
Altitude: < 2000 m
Relative Humidity:
85% maximum at 25C decreasing linearly to 50% at 40C.
Installation/Over voltage
Category:

Pollution Degree: 2
Indoor Use Only
Vibration: Designed to meet NSTA 1A transportation levels.
Shock: Designed to meet NSTA 1A transportation levels.
