Ametek CSW5550 User Manual

User Manual California Instruments
26 CSW Series
2.6 Special Features, Options and Accessories
Option Description
- 704 Mil Std 704D & E test firmware.
Mil Std 704A, B, C, & F test software (refer to Avionics Software Manual P/N
4994-971 for details).
Note: Requires use of CSWGui Windows application software provided on
CD ROM CIC496.
- 787 Boeing 787 Test software (refer to Avionics Software Manual P/N 4994-971
for details).
Note: Requires use of CSWGui Windows application software provided on
CD ROM CIC496.
- 160 RTCA/DO-160D test firmware
RTCA/DO-160E test software (refer to Avionics Software Manual P/N 4994-
971 for details)..
Note: Requires use of CSWGui Windows application software provided on
CD ROM CIC496.
- 411 IEC 1000-4-11 test firmware
- 413 IEC 1000-4-13 test hardware and firmware
-ABD Airbus ABD0100.1.8 Test software (refer to Avionics Software Manual P/N
4994-971 for details)..
Note: Requires use of CSWGui Windows application software provided on
CD ROM CIC496.
-AMD Airbus AMD24C Test software (refer to Avionics Software Manual P/N 4994-
971 for details)..
Note: Requires use of CSWGui Windows application software provided on
CD ROM CIC496.
-LAN Adds Ethernet interface (RJ45 connector) for local area network connection.
(Available on P/N 7000-485 and 7000-486 models only).
-LF Limits maximum output frequency to 500 Hz.
-FC Frequency accuracy is ± 0.15% of program value.
- RMS Rack mounting kit with slides. Removable rack ears/handles standard.
-LK Clock/ Lock Option. With this option enabled the programmed frequency
resolution is 1 Hz for all programmed values of frequency. If the upper
frequency limit is 819 Hz or less the standard program resolution applies.

Ametek CSW5550 Specifications

General

Brand	Ametek
Model	CSW5550
Category	Power Supply
Language	English
