Ametek CSW5550 User Manual

User Manual California Instruments
CSW Series 51
3.11.2 Overview of Menu 1
level 1 level 2 level 3
MENU 1 PROGRAM PROGRAM1
VOLTAGE
FREQ
VOLT RANGE
CURR LIMIT
MORE
PROGRAM2
PHASE
CLOCK MODE
VOLT MODE
DC OFFSET
START ø
MEASUREMENTS MEASUREMENTS1
VOLTAGE
CURRENT
FREQ
POWER
MORE
MEASUREMENTS 2
VA POWER
PEAK CURR
POWER FACT
CREST FACT
PEAK CURR RESET
MEASUREMENTS 3
VOLT THD
CURR THD
INST PK CURR
PHASE
HARMONICS/TRACE
ANALYSIS
FUNCTION
VIEW
DATA MODE
SCALE
TRIG MODE
TRIG SOURCE
TRIG PHASE
TRIG DELAY
START
TRANSIENTS VOLT SURGE/SAG START ø
VOLT SWEEP/STEP START ø GO TO VOLT
FREQ SWEEP/STEP DURATION END VOLT DUR SCALE
VOLT/FREQ SWEEP/STEP DURATION END FREQ DUR SCALE DURATION
START/VIEW SEQUENCE START END VOLT END DELAY DURATION END VOLT
PREVIOUS SCREEN PAUSE END FREQ FUNCTION END DELAY END DELAY
REPEAT #0 END DELAY REPEAT FUNCTION FUNCTION
CLEAR SEQ FUNCTION EVENT# REPEAT REPEAT
REPEAT PREVIOUS SCREEN EVENT# EVENT#
#1 SEQUENCE# PREVIOUS SCREEN PREV. SCREEN
#2 PREVIOUS SCREEN
..
#98
#99
PREVIOUS SCREEN
WAVEFORMS CLIP LEVEL
GROUP
MODE
SINE
SQUARE
CLIPPED
USER WAVE
..
..
MORE USER WAVE
