AMETEK CTS UCS 200N
Manual for Operation V 2.41 15 / 54
User Test Routines (pulse 1, pulse 2)
The user can program, save and recall his own specific test routines. The next pages shows the selection of the
functions.
F1 : Customized test routine
F2 : Voltage change after n by V
F1 : Customized test routine
F2 : Voltage change after n by V
Standard Test Routines (pulse 1, pulse 2)
The operating software of the UCS 200N includes several preprogrammed Standard Test Routines which can be
easily called up by pushing the related function key. All test parameters are set as specified in the standard, so
that the operator can start the test procedure immediately.
For Pulse 1 and Pulse 2 the basic standard is the ISO 7637-2:2004.
Pulse 1 test routine includes the following pulses: Pulse 2 test routine includes the following pulses:
- 1/1000s with Ri = 20 as per SAE J1113 - 1/50s with Ri = 2 as per ISO 7637
- 1/2000s with Ri = 10 as per ISO 7637 - 1/150s with Ri = 30 as per MBN 10284
- 1/6000s with Ri = 30 as per MBN 10284
- 3/1000s with Ri = 50 as per ISO 7637
- 3/2000s with Ri = 4 as per MBN 22100
All other pulse 1 and pulse 2 variations in other manufacturer specifications can be covered by selecting a
different internal resistor Ri or by using the Freestyle programming mode (see paragraph 10.5)
