AMETEK CTS UCS 200N
Manual for Operation V 2.41 37 / 54
Examples of manufacturer requirements:
MBN 10284 pulses
Pulse 1 (12V supply)
Rise time
1s +0% // -50%
Pulse duration
2 ms ±10%
Source impedance
10 ±10%
Pulse 1 (24V supply)
Rise time
1s +0% // -50%
Pulse duration
2 ms ±10%
Source impedance
10 ±10%
Pulse 1 Scenario 1 (42V supply)
Rise time
1s +0% // -50%
Pulse duration
6 ms ±10%
Source impedance
30 ±10%
Pulse 1 Scenario 2 (42V supply)
Rise time
1s +0% // -50%
Pulse duration
2 ms ±10%
Source impedance
90 ±10%
Pulse 2 (12V supply)
Rise time
1s +0% // -50%
Pulse duration
0,05 ms ±10%
Source impedance
10 ±10%
Pulse 2 (24V supply)
Rise time
1s +0% // -50%
Pulse duration
0,05 ms ±10%
Source impedance
10 ±10%
Pulse 2 Scenario 1 (42V supply)
Rise time
1s +0% // -50%
Pulse duration
0,15 ms ±10%
Source impedance
30 ±10%
Pulse 2 Scenario 2 (42V supply)
Rise time
1s +0% // -50%
Pulse duration
0,05 ms ±10%
Source impedance
90 ±10%
7.2.2.
Trigger
Automatic
Auto release with preselected parameters
Repetition rate
0.2s - 99.0s (1.0s SAE pulses)
Manual
Manual release of a single event
Extern
External release by external trigger
Battery switch
Switch off time selectable t2 = 0 - 10’000ms
7.2.3.
Input / Output
+/- output
safety laboratory plugs for max. 80 V / 50 A / 100 A / 200 A
Coupling
Coupling to + line (capacitive coupling)
Decoupling
by diode and battery switch
