AMETEK CTS UCS 200N
Manual for Operation V 2.41 36 / 54
JASO pulses as per JASO D 001
(only available for UCS 200Nx.2 models)
Pulse A2 (12V) JASO
Capacitor
C = 4.7F
Pulse duration 
(36,8%) = 2.5us ±30%
R1
0.6 ±10%
R2
0.4  ±10%
Polarity
Positive
Pulse B2(12V) JASO
Capacitor
C = 33F
Pulse duration 
(36,8%) = 2.0ms ±20%
R1
60 ±10%
R2
80  ±10%
Polarity
Negative
Pulse D2(12V) JASO
Capacitor
C = 2.2F
Pulse duration 
(36,8%) = 2.5us ±30%
R1
1.2 ±10%
R2
0.9  ±10%
Polarity
Positive
