SAE J1113 Pulses
SAE pulse 1a
Rise time
60s +0% // -50%
Pulse width 10%-10%
300s ±10%
Source impedance
30 ±10%
SAE pulse 1b
Rise time
1s +0/ -50%
Pulse width 10%-10%
1 ms ±20%
Source impedance
20 ±20%
SAE pulse 1c
Rise time
3s +0/ -50%
Pulse width 10%-10%
1 ms ±20%
Source impedance
50 ±20%
As options
SAE pulses as per SAE J 1455
SAE Mutual
Rise time
1s ±20%
Pulse width 37%-37%
15s ±20%
Source impedance
50 ±10%
SAE Inductive
Rise time
1s ±20%
Pulse width 37%-37%
1000s ±20%
Source impedance
20±10%
