AMETEK CTS UCS 200N
Manual for Operation V 2.41 34 / 54
7.2.
Micro pulses 1 & 2 as per ISO 7637-2
7.2.1.
Pulse specification and settings
No load
U = 20V - 200V ±10%
Voltage settings
20V - 600V in 5V steps
Pulses
pulses 1, 1a and 2 as per ISO 7637-2
Source impedance selectable
2, 4, 10, 20, 30, 50,, 90
and as option EXTERN (Rs = 10 +Rs
ext
.)
Polarity
positive / negative
FREESTYLE mode
Free programmable pulse parameters
Peak Voltage V
20V – 600V
Rise time tr (10% - 90%)
1s - 10s
Pulse duration td (10% - 10%)
50s – 10’000s
Polarity
positive / negative
Internal resistor Rs
2 - 450
At the rear of the UCS 200N any resistor can be connected to
realize other values then listed above
Operation
Front panel
Via function keys
iso.control software
Via user software
ISO 7637 pulses
Pulse 1 (12V battery supply)
Rise time
1s +0% // -50%
Pulse width
2ms ±10%
Source impedance
10 ±10%
Pulse 1a
Rise time
3s +0% // -50%
Pulse width
1ms ±10%
Source impedance
50±10%
Pulse 2a (12V/24V)
Rise time
1s +0% // -50%
Pulse width
0.05ms ±10%
Source impedance
2 ±10%
Note: Above the ISO standard voltages, the rise time may deviate from the 1us tolerance listed in the standard.
Pulse 6 (12V/24V)
Rise time
60s +0% // -50%
Pulse width
300s ±10%
Source impedance
30 ±10%
