AMETEK CTS UCS 200N
Manual for Operation V 2.41 23 / 54
5.
Micro pulse generation
Discharge switch:
The discharge switch is a highly reproducible semiconductor switch.
5.1.
Pulses as per ISO 7637
Testpulse 1
12V System
24V System
Vs Voltage
0 .. -100V
0 .. –600V
Ri Impedance
10
50
td Duration
2 ms
1 ms
tr Risetime
1s
3s
t1 (Rep) Repetition rate
0,5 - 5s
0,5 – 5s
t2 Switch off time
200 ms
200 ms
t3 (smallest possible time)
< 100s
<100s
Testpulse 2a
12V System
24V System
Vs Voltage
0 .. 50V
0 .. 50V
Ri Impedance
2
2
td Duration
50s
50s
tr Risetime
1s
1s
t1 (Rep) Repetition rate
0,2 - 5s
0,2 - 5s
t2 Switch off time
0 ms
0 ms
Testpulse 6
12V System
24V System
Vs Voltage
0 .. -300V
0 .. –300V
Ri Impedance
30
30
td Duration
300s
300s
tr Risetime
60s
60s
t1 (Rep) Repetition rate
15s
15s
t2 Switch off time
1s
1s
t3 (smallest possible time)
< 100s
<100s
