Ametek UCS 200N .2 Series - Pulses as Per MBN 10 284 Part 2: August 2001; Pulses as Per NBM 22100 -2: August 1999

AMETEK CTS UCS 200N
Manual for Operation V 2.41 26 / 54
5.4.
Pulses as per MBN 10 284 part 2 : August 2001
Testpulse 1
12V System
24V System
42V System
Scenario 1
42V b System
Scenario 2
Voltage Vs
-100V
-300V
-100V
-300V
Internal resistor Ri
10
10
30
90
Duration td
2 ms
2 ms
6 ms
2 ms
Rise time tr
1s
1s
1s
1s
Repetition rate t1 (Rep)
5s
5s
5s
5s
Switch off time t2
200 ms
200 ms
200 ms
200 ms
t3 (smallest possible time)
< 100s
<100s
<100s
<100s
Testpulses
5000
5000
5000
5000
Testpulse 2
12V System
24V System
42V a System
Scenario 1
42V b System
Scenario 2
Voltage Vs
100V
150V
100V
300V
Internal resistor Ri
10
10
30
90
Duration td
0,05 ms
0,05 ms
0,15 ms
0,05 ms
Rise time tr
1s
1s
1s
1s
Repetition rate t1 (Rep)
5s
5s
5s
5s
Switch off time t2
200 ms
200 ms
200 ms
200 ms
Testpulses
5000
5000
5000
5000
Testpulse 1
Testpulse 2
5.4.1.
Pulses as per NBM 22100 –2 : August 1999
Testpulse 1
12V System
24V System
Impulseform
Voltage Vs
-150V
-300V
Internal resistor Ri
4
4
Duration td
2 ms
2 ms
Rise time tr
1s
3s
Repetition rate t1 (Rep)
0.2s
0.2s
Switch off time t2
200 ms
200 ms
t3 (smallest possible time)
< 100s
<100s
Testpulses
50’000
50’000
Testpulse 2
12V System
24V System
Impulseform
Voltage Vs
100V
150V
Internal resistor Ri
4
4
Duration td
50s
50s
Rise time tr
1s
1s
Repetition rate t1 (Rep)
0.5s
0.5s
Switch off time t2
200 ms
200 ms
Testpulses
5’000
5’000
