72 ASC110/ASC130/ASC150/ASC200/ASC250
2.6. Controls and control devices
Drum traction slip control switch (38)
Located on the control panel if the machine is not equip-
ped with ASC - Anti Slip Control function.
The lamp in the switch indicates the function on.
! WARNING!
Apply traction slip control only for driving up to
platforms of transporting vehicles.
Selector (2) must be off while switch (38) is on. At
the same time, vibration is locked.
Heating fan switch (39)
position - off
position - high speed of fan motor
position - low speed of fan motor
Fan ensures air circulation inside the cabin only.
Vibration pre-selector (40)
Position - low amplitude and high frequency is
on
Position - high amplitude and low frequency is
on
