Weighing mode = Normal batching, Loss-in-weight batching, Simple comparison normal batching, Simple
comparison loss-in-weight batching
Setpoint setting method = 16-digit input from external devices
Pin No. Description Description Pin No.
A1 BCD input 1 Preliminary 10^0 B1
A2 BCD input 2 Preliminary 10^1 B2
A3 BCD input 4 Preliminary 10^2 B3
A4 BCD input 8 Preliminary 10^3 B4
A5 Final weight 10^0 Overweight 10^0 B5
A6 Final weight 10^1 Overweight 10^1 B6
A7 Final weight 10^2 Underweight 10^0 B7
A8 Final weight 10^3 Underweight 10^1 B8
A9 Final weight 10^4 NC B9
A10 Free fall 10^0 NC B10
A11 Free fall 10^1 NC B11
A12 Free fall 10^2 Shield B12
Weighing mode = Check weighing 1, Check weighing 2
Setpoint setting method = 16-digit input from external devices
Pin No. Description Description Pin No.
A1 BCD input 1 Hi limit 10^3 B1
A2 BCD input 2 Hi limit 10^4 B2
A3 BCD input 4 Lo limit 10^0 B3
A4 BCD input 8 Lo limit 10^1 B4
A5 Target 10^0 Lo limit 10^2 B5
A6 Target 10^1 Lo limit 10^3 B6
A7 Target 10^2 Lo limit 10^4 B7
A8 Target 10^3 NC B8
A9 Target 10^4 NC B9
A10 Hi limit 10^0 NC B10
A11 Hi limit 10^1 NC B11
A12 Hi limit 10^2 Shield B12
