Weighing mode = Check weighing 3
Setpoint setting method = 16-digit input from external devices
Pin No. Description Description Pin No.
A1 BCD input 1 Hi limit 10^3 B1
A2 BCD input 2 Hi limit 10^4 B2
A3 BCD input 4 Lo limit 10^0 B3
A4 BCD input 8 Lo limit 10^1 B4
A5 NC Lo limit 10^2 B5
A6 NC Lo limit 10^3 B6
A7 NC Lo limit 10^4 B7
A8 NC NC B8
A9 NC NC B9
A10 Hi limit 0^0 NC B10
A11 Hi limit 10^1 NC B11
A12 Hi limit 10^2 Shield B12
Weighing mode = Check weighing 4
Setpoint setting method = 16-digit input from external devices
Pin No. Description Description Pin No.
A1 BCD input 1 Lo limit 10^0 B1
A2 BCD input 2 Lo limit 10^1 B2
A3 BCD input 4 Lo limit 10^2 B3
A4 BCD input 8 Lo limit 10^3 B4
A5 Hi-Hi limit 10^0 Lo-Lo limit 10^0 B5
A6 Hi-Hi limit 10^1 Lo-Lo limit 10^1 B6
A7 Hi-Hi limit 10^2 Lo-Lo limit 10^2 B7
A8 Hi-Hi limit 10^3 Lo-Lo limit 10^3 B8
A9 Hi limit 10^0 NC B9
A10 Hi limit 10^1 NC B10
A11 Hi limit 10^2 NC B11
A12 Hi limit 10^3 Shield B12
