LCX 890 Installation Guide 27
Figure 8. Location of Inputs, Outputs, and Momentary Switches
on the LCX 890
LCX 890
INPUTS
EMX 170
or
SP 100
Port
Universal
Inputs
Digital
Inputs
24 VAC
Rectified
Power
Terminal for
Occupancy
Sensor
Output
Relays
(Max Number
Possible
Shown—24)
Momentary
Switches
