54 LCX 890 Installation Guide
Powering Up the LCX 890 or 898
Warning
Before powering up the controller, be sure the board is jumpered for the
correct input voltage.
Before you proceed, be sure the following are correct:
1. Be sure you have jumpered the proper input voltage.
2. Be sure the battery is connected.
3. Be sure the AC power is wired properly. Check to be sure you have
connected all three wires.
4. Be sure the controller has a true earth ground.
5. Be sure you have used the proper cables and wires and correct
lengths.
6. Be sure you have properly labeled the tag with the name of the
controller before removing it.
7. Be sure you have properly wired the Infinet cable.
8. Be sure you have properly connected the Infinet cable shields.
If you have completed all previous sections in this manual, you are now
ready to power up the controller.
Turn on the AC power source (or close the power connection) and the
controller starts automatically. The following occurs (also occurs when
you press RESET):
1. The CPU light begins flashing and flashes every .2 sec.
2. The TD light immediately starts flashing (or starts flashing after you
let go of the RESET button) to show data is being transmitted.
