Anritsu Spectrum Master MS2720T User Manual

4-8 Scanner Menu Channel Scanner (Option 27)
4-8 PN: 10580-00349 Rev. H Spectrum Analyzer MG
Freq Scan Menu
Key Sequence: Scanner > Scan Frequencies > Scan Frequencies
Start Freq: Sets the center frequency of the first channel to be displayed.
Freq Step Size: Sets the spacing between frequencies on the display.
Bandwidth: The channel bandwidth can be manually entered
in GHz, MHz, kHz, or Hz.
Number of Channels: Sets the number of channels to be displayed
(1 to 20).
Back: Returns to the “Scanner Menu” on page 4-7.
Figure 4-4. Channel Scanner Frequency Scan Menu
Back
Freq Scan
Start Freq
580.000 kHz
Freq Step Size
10.000 kHz
Bandwidth
9.000 kHz
Number of Channels
20
