4-9 Amplitude Menu Channel Scanner (Option 27)
4-10 PN: 10580-00349 Rev. H Spectrum Analyzer MG
4-9 Amplitude Menu
Key Sequence: Amplitude
Reference Level: Activates the amplitude reference level function which
sets the amplitude at the top of the display. Valid reference levels are from
+30 dB to –130 dBm.
Scale : Activates the scale function which sets the dB/division value from
1 dB/div to 15 dB/div in 1 dB steps.
Figure 4-6. Channel Scanner Amplitude Menu
Amplitude
Reference Level
10.0 dBm
Scale
10 dB/div
