7-17 Audio Waveform PM Menu AM/FM/PM Analyzer (Option 509)
7-24 PN: 10580-00349 Rev. H Spectrum Analyzer MG
7-17 Audio Waveform PM Menu
Key Sequence: Measure or (Shift + 4) > Audio Waveform > Audio Waveform
Sweep Time: Press to set the sweep time for the PM audio waveform
display. If you use the numeric keypad to enter a value, then the submenu
keys change to Time in units of min, s, ms, or µs.
Scale milli-Rad: Press to set the vertical scale in milliradians. Use the
numeric keypad, the rotary knob, or the arrow keys to enter a value.
Squelch Power: Press to set the squelch power level.
Back: Press to return to the Measurements menu.
Figure 7-21. Audio Waveform PM Menu
Back
Scale milli–Rad
####
Squelch Power
#### dBm
Sweep Time
## s
Audio Waveform
PM
