AM/FM/PM Analyzer (Option 509) 7-18 Coverage Mapping Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 7-25
7-18 Coverage Mapping Menu
Key Sequence: Measure or (Shift + 4) > Coverage Mapping
On Off: Toggles Coverage Mapping On or Off. The current map or the
default grid is displayed when Coverage Mapping is On. When Off, the
instrument shows the standard measurement display.
Save/Recall Points/Map: Press this submenu key to open the “Mapping
Save/Recall Menu” on page 7-26, where you can save the mapping
information or recall a map.
Measurement Setup: Press this submenu key to open the “Measurement
Setup Menu” on page 7-27 and select the coverage measurement type and
threshold values.
Point Distance/Time Setup: Press this submenu key to open the “Point
Distance/Time Setup Menu” on page 7-28 and set up the Time or Distance
interval for capturing data.
Back: Returns to the “Measurements Menu” on page 7-17.
Start/Stop Data Collection: Press this main menu key to start coverage
mapping data collection based on Measurement Setup settings and Point
Distance/Time Setup settings. A running count of collected data points is
displayed at the bottom of the map. Press again to stop data collection.
Figure 7-22. AM/FM/PM Coverage Mapping Menu
