AM/FM/PM Analyzer (Option 509) 7-18 Coverage Mapping Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 7-27
Measurement Setup Menu
Key Sequence: Measure or (Shift + 4) > Coverage Mapping > Measurement Setup
Measurement: Press this button to select coverage measurement. Choose
between SINAD, Carrier Power or Both (Multiple). The button displays the
current measurement selection. When Multiple is selected, the colors
displayed on the instrument and in Google Earth are determined by the
Carrier Power measurements, based on the specified threshold levels.
SINAD Thresholds: Press this button to select the threshold values for
SINAD measurements. Each threshold corresponds to a specific mapping
point color during coverage mapping (Figure 7-4 on page 7-7). Threshold
values can also be changed with the touch screen by pressing on one of the
color boxes in the map legend.
Carrier Power Thresholds: Press this button to select the threshold values
for Carrier Power measurements. Each threshold corresponds to a specific
mapping point color during coverage mapping. Threshold values can also be
changed with the touch screen by pressing on one of the color boxes in the
map legend.
Back: Returns to the “Coverage Mapping Menu” on page 7-25.
Figure 7-24. AM/PM/FM Coverage Mapping Measurement Setup Menu
Back
Measurement Setup
Measurement
SINAD
SINAD
Thresholds
Carrier Power
Thresholds
