9-3 EMF Menu EMF (Option 444)
9-2 PN: 10580-00349 Rev. H Spectrum Analyzer MG
9-3 EMF Menu
Key Sequence: Shift > Measure (4) key > Power and Bandwidth > EMF Measurement
On/Off: This is the main EMF Measurement On/Off button. Press this key to
switch EMF On and Off. The start and stop frequencies must be within the
range of the spectrum analyzer and isotropic antenna used, and the antenna
must be connected. The detection type is automatically changed to RMS/Avg
when EMF is On. It is restored to the previous detection setting when EMF is
Off.
Note: You are prompted with warning messages if the antenna is not
connected or if the frequency span of the analyzer is outside the antenna
range.
Automated Measurements: Opens the “EMF Auto Menu” on page 9-3
where you can set up EMF parameters and start the measurement. EMF
must be turned On.
Limits: This is a shortcut to the standard spectrum analyzer Limits menu
(Shift > Limit (6)). For EMF measurements, only the upper limit line is used
for testing the pass/fail condition. Multi-segment limit lines can also be
created.
ICNIRP Limit On/Off: Turning this On creates a limit line consistent with the
guidelines of the International Commission on Non-Ionizing Radiation
Protection. Trace C contains the averaged isotropic result and is tested
against this limit line, and then the Pass/Fail status is updated.
Units: The unit choices are dBm/m
2
, dBV/m, dBmV/m, dBuV/m, V/m, W/m
2
,
dBW/m
2
, A/m, dBA/m, W/cm
2
. dBm/m
2
is the default.
Trace: Opens the “Trace Menu” on page 9-4.
Back: Returns to the “Power and BW Menu” on page 2-69.
Figure 9-2. EMF Menu
