9-3 EMF Menu EMF (Option 444)
9-4 PN: 10580-00349 Rev. H Spectrum Analyzer MG
Trace Menu
Key Sequence: Shift > Measure (4) key > Power and Bandwidth > EMF Measurement > Trace
Trace: Selects one of three traces, each holding a different result.
Axis: Holds the sweep result for the currently selected axis.
Result: The isotropic result (X
2
+Y
2
+Z
2
)
0.5
at the end of an X, Y, Z
sweep.
Avg: Holds the isotropic result from trace averaging (Volts on a linear
scale). This is the running average of the individual isotropic
measurements completed within the specified measurement time.
View/Blank: Toggles the selected trace between View and Blank state. Two
or all three traces can be viewed simultaneously by selecting each trace and
setting its state to View. Selecting Blank will blank the currently selected
trace.
Back: Returns to the “EMF Menu” on page 9-2.
Figure 9-4. Trace Menu
Trace
Trace
Axis Result Avg
View
Blank
Back
