2-13 Measurements Menu CDMA Signal Analyzer
2-24 PN: 10580-00235 Rev. D 3GPP2 MG
2-13 Measurements Menu
Key Sequence: Measurements
RF Measurement: Opens the “RF Measurements Menu” on page 2-25.
Demodulator: Opens the “Demodulator Menu” on page 2-26. In
demodulator mode, the received CDMA signal is demodulated. The
demodulator has three measurement displays: CDP, CDP Table, and
Modulation Summary.
OTA: Opens the “Over-The-Air Menu” on page 2-27. OTA displays the
CDMA Over-The-Air measurements, which include: Pilot Codes, Ec/Io (dB),
Tau, Pilot Power, Channel Power, Pilot Dominance, and Multipath.
Pass Fail Mode: The first press of this submenu key puts the instrument into
Pass Fail Mode. The next press of the submenu key opens the “Pass Fail
Mode Menu” on page 2-29.
CDMA Summary: Displays a summary of all of the CDMA-related numerical
measurements in a table format.
Save Measurement: Opens a dialog box to name and save the current
measurement. Press Enter to save the CDMA measurement, which is saved
with a .cdma extension.
Figure 2-18. CDMA Measurements Menu
Measurements
RF Measurements
Demodulator
OTA
Pass/Fail
Mode
CDMA
Summary
Save
Measurement
