CDMA Signal Analyzer 2-14 Marker Menu
3GPP2 MG PN: 10580-00235 Rev. D 2-29
Pass Fail Mode Menu
Key Sequence: Measurements > Pass Fail
2-14 Marker Menu
Key Sequence: Marker
Press the Marker main menu key to open the Marker menu. The instrument is equipped with
six markers. Any or all markers can be employed simultaneously.
Select Pass/Fail Test: This submenu key function allows the selection of a
user-defined file that specifies a list of measurements with pass fail criteria.
Select a test model by using the arrow keys or rotary knob. This mode will
sequentially assess the appropriate measurements and indicate a pass or
fail state based upon the test model criteria. Custom pass fail tests can be
created by using Master Software Tools.
Reset: Press this submenu key to restart the measurement.
Back: Returns to the “Measurements Menu” on page 2-24.
Figure 2-25. CDMA Pass Fail Mode Menu
Markers are available only in CDP and Spectrum measurements.
Marker: Selects the active marker (1 to 6). The underlined marker number
is the active marker. Each press of the submenu key moves the underline to
the next marker number. Pressing Shift causes reverses the direction of
marker selection. Press the Shift button again to change back to the original
direction.
On/Off: Turns the selected marker underlined in the Marker submenu key
On or Off.
Marker Table On/Off: Causes a table to be displayed below the sweep
window. The table is automatically sized to display all markers that are
turned on. In addition to the marker frequency and amplitude, the table also
shows delta frequencies and amplitude deltas for all markers that have
deltas entered for them.
All Markers Off: Turns off all markers.
Figure 2-26. CDMA Marker Menu
Select
Pass/Fail
Test
Back
Reset
Marker Table
On Off
Marker
On
Off
All
Markers
OFF
Marker
1 2 3 4 5 6
