EVDO Signal Analyzer 3-5 EVDO Demodulator Measurements Setup
3GPP2 MG PN: 10580-00235 Rev. D 3-7
3-5 EVDO Demodulator Measurements Setup
EVDO demodulator measurements include, CDP MAC, CDP Data, MAC CDP table, and
Modulation Summary. To demodulate EVDO signals, connect the instrument to the base
station by using the following setup instructions:
1. Press the Setup key to open Setup menu.
2. Press the PN Setup submenu key and choose the trigger type: No Trigger (No Trig), GPS,
or External (Ext).
3. Press PN Search Type submenu key to toggle between Auto and Manual search.
4. Press Back to go to the previous menu.
5. Press the Walsh Codes submenu key to choose 64 codes or 128 codes.
6. Press the Measurement main menu key to open the measurements menu.
7. Press the Demodulator submenu key to activate the Demodulator measurements menu.
Note
If Manual Search is selected, then press Manual PN Offset submenu key and
enter the PN value manually.
